Hybrid Drivetrain – Flywheel Energy Storage Technology

Project Overview

A global manufacturer of hybrid drivetrain systems for the motorsport and transportation industries partnered with H V Wooding Ltd to support the development of advanced flywheel energy storage technology. This innovative solution enables significant fuel savings and reduces greenhouse gas emissions by up to 30% in public transport vehicles such as city buses, contributing to a more sustainable and energy-efficient future.

Challenge

The project required the design and manufacture of tooling for laminations made from 0.1mm electrical steel, with exceptionally tight tolerances of below 30 microns. The customer needed prototype solutions that could transition seamlessly into volume production, ensuring both scalability and quality. Additional challenges included achieving a burr-free stamping process and establishing a reliable material supply chain for this specialist grade of steel.

Solution

H V Wooding developed a bespoke supply chain to source the required raw materials and worked closely with the customer to finalise the geometry of the lamination profile. Prototype samples were produced via wire erosion, enabling detailed testing and validation. The team then designed and manufactured complex compound tooling for full-scale production, incorporating a custom catcher unit to safely remove parts from the tool. In-process inspection was carried out using a dedicated CMM programme to ensure consistent accuracy and quality at every stage.

Results

The collaboration delivered high-quality laminations that met all technical specifications and performance expectations. H V Wooding developed a cost-effective and repeatable production process, establishing a secure material supply chain where none had previously existed. The customer received the first laminations of their kind for this application, supporting both prototype validation and future production planning.

Added Value

The project provided the customer with a clear competitive advantage in hybrid drivetrain and flywheel energy storage technology. H V Wooding’s innovative tooling and process design optimised future product scalability and created a robust manufacturing platform for next-generation systems. Additionally, by leveraging its extensive industry network, H V Wooding helped to enhance the customer’s supply chain, introducing complementary partners who added further value to the overall project.
